TECHNICAL PARAMETER
| Name | Unit | QTY | Name | Unit | QTY |
| Engine | KW | 194/2200 | Dimention(L*W*H) | mm | 7780x2300x2485 |
| Max. Push force | KN | 460 | Weight | T | 14.1 |
| Max. pulling force | KN | 890 | Rod diameter | mm | Φ89 |
| Max torque | N.m | 27000 | Rod length | m | 3 |
| Max. rotation | rpm | 130 | Max. Dia of Pulling pipe | mm | Φ1200 |
| Travel speed | m/min | 30 | Length of | m | ~900M |
| Flow | L/min | 600 | Angle of incidence | - | 11~20 |
| Max.Mud pump pressure | Mpa | 10±0.5 | angle of travel | - | 14 |
| MAIN PARTS | Specification | Brand |
| Engine | QSC8.3-C260(194kw) | Cummins |
| Rotation pump | 90R100 | Danfus |
| Push-pull pump | A2F16R2A4 | shanghai |
| Push-pull pump | 75(75+42+16) | permco |
| Auxiliary pump | 75+42 | permco |
| Mud pump | BW600 | elephant |
| Rotation motor | MHP20 | POCLAIN |
| push-pull cylinder | YONGJIAN | |
| Track motor | TM09VC | RECLAIM |
| Push-pull valve | 5AGCJX-G20L-3Y20-5K-5C-5C | |
| Hydralic-Valve | JHP-11S-G28-A02(Thrus) | YOULI |
| JHP-11S-G2FD-A01B(Rotation) | YOULI | |
| auto-Arm |
