TECHNICAL PARAMETER
| Engine | KW | 264/2200 | Machine Dimensions | mm | 10559x2630x3315（(L*W*H)） |
| Maximum push force | KN | 550 | Machine weight | T | 28 |
| Maximum pull-back force | KN | 1320 | Dia of drill pipe | mm | ψ114 |
| Max. torque | N.m | 42000 | Length of drill pipe | m | 4.5 |
| Max carriage rotation speed | rpm | 100 | Dia of max pull-back | mm | ψ1300 |
| Max. traveling speed of power head | m/min | 30 | Max. length paved | mm | ~900 |
| Flow of mud pump | L/min | 800 | Angle of incidence | - | 8~18 |
| Max. pressure of mud | Mpa | 10±0.5 | Climbing angle | - | 14 |
Main Parts
| Engine | Cummins |
| Rotary pump | Sauer Danfoss, USA |
| Push/pull pump | Sauer Danfoss, USA |
| Auxiliary pump | Permco, USA |
| Mud pump | Leike, China |
| Rotary motor | Poclain, France |
| Pushing cylinder | Yongjian, China |
| Motor for track | Doosan, Korea |
| Push/pull valve | Sauer Danfoss, USA |
| Auxiliary valve | Walvoil, Italy |
| Filter | PALL, USA |
| Crane | 2 Ton, wire control |
